HT-SKP3-1-HT-SSP3/S2430

Product number:
High-Temperature Resistant Actuator and Sensor Cable, Extension Cable, M8 female connector, straight, 3-pin, Sheath material: PTFE, Sheath color: white, Flame-retardant, Resistant to welding sparks, Resistant to chemicals, UV radiation and oils, Resistant to acids and alkaline solutions, LABS free, Resistant to microbes and hydrolysis, Cold and heat-flexible, RoHS-compliant, Protection class IP65, Temperature range of the cable: -190°C…260°C, Cable length 1 m, M8 male connector, straight, 3-pin

Download specifications
NameValue
Number of poles3
Type of electrical connection, field-sidedM8
Type of plug-in contact, field sidedMale (plug)
Positioning cable feed, field-sidedStraight
Type of electrical connection, box-sidedM8
Type of plug-in contact, box-sidedFemale (bus)
Positioning cable feed, box-sidedStraight
Cable length1 Meter
Material of cable sheathOther
Halogen free- MV
Colour cable sheathWhite White
With LED indicationNo
ScreenedYes
Type of cableMulti-core
Vulcanize- MV
Material contact bodyCuZn
Material of contact surfaceAu
Permitted cable outer temperature, fixed-20, 150 Degrees celsius
Permitted cable outer temperature, in movement- MV Degrees celsius
Rated current In4 Ampere
Nominal rated voltage250 Volt
Continuity resistor- MV Milli-Ohm
Customs tarif #:85444290900
UNIT:Piece
GTIN4047106278731
