Product number:
Food & Beverage Hygienic, TPE, Connection Cable, M12 female connector, straight, 5-pin, Stainless steel coupling nut/screw, Cable length: 0.5 m, Sheath material: TPE-O, Sheath color: light gray RAL 7035, Qualified for drag chain use, Resistant to chemicals an microbes, Weatherproof, Resistant to hydrolysis acc. to DIN EN 60068-2-78, Flexible at low temperatures, Free from silicone and PVC, Halogen-free acc. to DIN EN 50267-2-1, IEC 60754-1, VDE 0482-267-2-1, Approvals: Gost, Ecolab, FDA, RoHS and REACH compliant, Protection classes IP67, IP69K

Download specifications
Number of poles5
Type of electrical connection, field-sided- MV
Type of plug-in contact, field sided- MV
Positioning cable feed, field-sided- MV
Type of electrical connection, box-sidedM12
Type of plug-in contact, box-sidedFemale (bus)
Positioning cable feed, box-sidedStraight
Cable length0.5 Meter
Material of cable sheathOther
Halogen free- MV
Colour cable sheathGrey Gray
With LED indicationNo
Type of cableMulti-core
Vulcanize- MV
Material contact bodyCuZn
Material of contact surfaceAu
Permitted cable outer temperature, fixed-40, 105 Degrees celsius
Permitted cable outer temperature, in movement-25, 105 Degrees celsius
Rated current In4 Ampere
Nominal rated voltage60 Volt
Continuity resistor- MV Milli-Ohm
Customs tarif #:85444290900
