VAS22-E80E-5/TEL
Product number:
Valve connector A type, Connection Cable, Cable length: 5.0 m, Sheath material: PVC, Sheath color: black, Resistant to chemicals and oils, Flame retardant, Resistant to acids and alkaline solutions, Resistant to microbes and hydrolysis, LABS-free
Download specifications
Name | Value |
---|---|
Number of poles | - MV |
Type of electrical connection, field-sided | - MV |
Type of plug-in contact, field sided | - MV |
Positioning cable feed, field-sided | - MV |
Type of electrical connection, box-sided | Other |
Type of plug-in contact, box-sided | Male (plug) |
Positioning cable feed, box-sided | - MV |
Cable length | 5 Meter |
Material of cable sheath | PVC |
Halogen free | - MV |
Colour cable sheath | Black Black |
With LED indication | No |
Screened | Yes |
Type of cable | Multi-core |
Vulcanize | - MV |
Material contact body | CuSn |
Material of contact surface | Ag |
Permitted cable outer temperature, fixed | -40, 105 Degrees celsius |
Permitted cable outer temperature, in movement | 0, 80 Degrees celsius |
Rated current In | 4 Ampere |
Nominal rated voltage | - MV Volt |
Continuity resistor | - MV Milli-Ohm |
Customs tarif #: | 85444290900 |
UNIT: | Piece |
GTIN | 4047101338416 |
